Saniflow Sanislim for slimline sanitaryware. Add a washroom, shower unit or even a complete en suite shower room based on slimline sanitaryware. Ideal for use in a basement or loft extension - or in any home improvement where conventional large bore pipework is impractical.
Motor: induction motor (no carbon brushes or gears to wear out). Tested over 30,000 cycles.
Watts (consumption): 400w
Flow rate at max head l/min: 47
Electrical supply: 220-240V 50Hz
Discharge horizontally to 40 metres or vertically to 4 metres
Gravity fall on ‘horizontal’ installations: 1:100
Discharge Pipe Diameter: 22mm
Construction Materials: Polypropylene, C.R.P., stainless steel, Neoprene
Type of WC Pan: (not included)
Short spigot 100mm HO outlet (BS EN 33/37)
Motor RPM: 2800 RPM
Normal Running Time WC:
10 - 20 secs approx or as required, to discharge shower etc
Dimensions:
435W x 315 O/H x 140D (requires 145mm behind spigot)
A clearance of 375mm is required from floor level to the underside of a close-coupled suite to accomodate the discharge elbow.
Note: Designed to fit BS EN 33/37 WC pans.
Sanitaryware not included.
Product Code: SF-SANISLIM
Saniflo macerator pumping systems enable you to add facilities almost anywhere. They're easy, quick and economic to install and you can add a cloakroom or complete bathroom - even a kitchen or utility room!
Saniflo macerator come with a 2 year manufacturers guarantee for domestic use.
For a product brochure, and technical details of these products visit www.saniflo.co.uk
